30-IN-1 READER. Read & Write: SD, SDHC, SD Ultra II MiniSD*, Micro SD, MMC/MMCII, RSMMC*, Compact Flash Type 1 & 2, Microdrive, Smart Media, xD Picture card, Memory Stick/Pro/Duo/M2. USB 2.0, Alcor Au6375 chipset. 1 year warranty.

Features

  • Reads & Writes Secure Digital, MiniSD, Micro SD, MMC/MMCII, RSMMC, SDHC Compact Flash Type 1 & 2, Microdrive, Smart Media, xD Picture card, Memory Stick/Pro/Duo
  • USB 2.0 Type A to B cable & driver
  • disc included
  • Suits Win98/SE, ME, 2000, XP,
  • Vista & Mac OS, Win 7

(SH-XCR3)

Reader Type Smart Card Reader: Mechanical and Contact Free
Mechanical in accordance with ISO7816
Contact Free in accordance with ISO14443A, ISO14443B, ISO15693
Card Feed Method Mechanical feed
Contactl free Reader
Read/Write Function Mechanical: Read and Write
Contactless: Read only
Card Type Compatible Chipcards types: MIFARE, DESFire, iCLASS
Reads and Writes to all ISO7816 cards
Card Feed Speed N/A
Card Data Format N/A
Chipcard Protocol T=0, T=1, T=CL
Transmission Speed Reader Card: max. 420kBit/sec (ISO7816), 424 kBit/sec (ISO14443) , 26 kBit/sec (ISO15693)
Reader System: max. 12Mbits/sec
Chip Card pulse Frequency; up to 8 MHz
Software Interface CT-Api, PC/SC, CCID
Programming Method N/A
Indicators/Controls LED Status Display
Communication Type Cabled, Bi-directional Communication
Interfaces USB - Ver. 2.0
Supply Voltage 5 V 5 %
Power Consumption Typical. 160 mA
Operating Environment 0 to 50 C
RH 5 - 90 % (non-condensing)
Storage Environment -20 to 65 C
RH 5 - 90 % (non-condensing)
External Dimensions (WxDxH) 115 x 75 x 16.51 mm
Weight approx. 105 g (excl. cable)
SKU SH-XCR3
Barcode # 9328157001000
Brand Shintaro
Brand Shintaro
Type Card Reader
Model SH-XCR3
Shipping Cubic 0.017794000m3
