The SE-8P provides 8*10/100/1000Mbps Gigabit ports with 8-port PoE+, making it an excellent choice for a fast, cost effective and reliable networking infrastructure. The store-and-forward architecture filters errors and forwards packets in a non-blocking environment. Flow control ensures the accuracy of the data transmitted. The PoE+ on the SE-8P supplies power for connected devices that need it. Over current protection and circuit shorting protection are also supported.

The switch was designed for easy installation and maintenance. It supports the Nway auto-negotiation protocol that detects networking speed (10/100/1000 Mbps) and duplex modes (Full/Half) automatically. Auto-MDI/MDI-X function alleviates the need for crossover cables. Also, rich diagnostic LEDs are provided for real-time connection status information.

Key Features

  • Complies with 10BASE-T specifications of the IEEE802.3 standard
  • Complies with 100BASE-TX specifications of the IEEE802.3u standard
  • Complies with 1000BASE-T specifications of the IEEE802.3ab standard
  • Complies with IEEE 802.3af/at PoE standard
  • Supports 31.5W maximum per PoE port
  • Supports over current protection and circuit shorting protection
  • 8* 10/100/1000Mbps RJ-45 Nway ports
  • Supports NWay protocol for speed (10/100/1000Mbps) and duplex mode (Half/Full) auto-detection
  • Supports MDI/MDI-X auto crossover
  • Supports full and half duplex operation on all ports
  • Wire-speed packet filtering and forwarding rate
  • Store-and-forward architecture filters fragment & CRC error packets
  • Supports 8K MAC address entries in whole system

(SE-8P-NoRack-R)

Standard IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3x full-duplex flow control
IEEE802.3ab 1000BASE-T
IEEE 802.3af/at PoE standard (DTE power via MDI)
Interface 8*10/100/1000 Mbps auto MDI/MDI-X RJ-45 switching ports
Supports 136W Max;
Full load:
31.5W(at) x 4 Ports
15.4W(af) x 8 Ports
Cable Connections RJ-45 (10BASE-T): Category 3,4,5 UTP/STP
RJ-45 (100BASE-TX): Category 5 UTP/STP
RJ-45 (1000BASE-T): Category 5,5e or enhanced UTP/STP
Transmission Mode 10/100Mbps Full-duplex, Half-duplex
1000Mbps Full-duplex
LED indications 1 * power LED
8 * Link/ACT LEDS
8 * PoE LEDS
1 * loop LED
Memory 8K MAC entries
9216 bytes jumbo packet length
128K bytes Buffer Memory
Emission FCC & CE
Safety LVD
Operating Temperature -0 °C-40 °C (32 °F-104 °F)
Operating Humidity 10% - 90% (non-condensing)
Power Supply Internal power supply
100-240V/47-63 Hz universal input
Dimensions & Weight 7.30 x 12.68 x 1.73 in (18.54 x 32.21 x 4.39 cm)
4.3 lbs (1.95 kg)
SKU SE-8P-NoRack-R
Barcode # 615678942295
Brand Pakedge
Brand Pakedge
Type Unmanaged Switch
Model SE-8P
PoE Ports 8
Shipping Cubic 0.004300000m3
