Juniper Networks EX-SFP-1GE-SX compatible SFP transceiver supports up to 550m link lengths over multi-mode fibre (MMF) using a wavelength of 850nm via an LC connector. Each SFP transceiver module is individually tested to be used on a series of Juniper switches, routers, servers, network interface card (NICs) etc. Featuring low power consumption, the hot swappable 1G SFP transceiver is ideal for Internet Service Provider (ISP) Gigabit Ethernet communication links, Enterprise LAN & SAN Networks, Data Center LAN & SAN Networks and other optical links.

(JuiperEX-SFP-1GE-SX)

Juniper Networks Compatible

EX-SFP-1GE-SX

Vendor Name

FS

Form Factor

SFP

Max. Data Rate

1.25Gbps

Wavelength

850nm

Max. Cable Distance

550m@50/125µm OM2 MMF
275m@62.5/125µm OM1 MMF
220m@62.5/125µm FDDI MMF

Connector

Duplex LC

Media

MMF

Transmitter Type

VCSEL

Receiver Type

PIN

DDM/DOM

Supported

Operating Temperature Range

0 to 70°C (23 to 158°F)

TX Power

-9.5 ~ -3dBm

Receiver Sensitivity

< -17dBm

Typical Power Consumption

≤0.8W

Receiver Overload

-3dBm

Bit Error Ratio (BER)

1E-12

Extinction Ratio

>9dB

EMC (Electro Magnetic Compatibility)

Supported

MTBF (SX)

2,457,002 Hours

Protocols

IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant



SKU JuiperEX-SFP-1GE-SX
Barcode # 832938038677
Brand Juniper Networks
Brand Juniper Networks
Type Transceiver Module
Model EX-SFP-1GE-SX
Shipping Cubic 0.017794000m3
