Fast, powerful POS printing with front exit

  • High Speed Direct Thermal Printing
  • Paper exit from the front for better splash proofing
  • Up to 200mm/sec providing fast printing results for customers.
  • Longer cutter life delivers lower maintenance costs
  • Greater reliability delivers longer life & lower maintenance costs
  • Wider paper width allows printing of additional information & larger fonts
  • USB standard meets market standardization requirements
  • 2D/PDF417 bar code support
  • Built in buzzer provides audible alert without adding extra cost devices
  • Built in power supply eliminates unsightly "brick" and frees up space
  • Printer drivers included are: Windows XP (32 and 64 bit), Windows Vista (32 and 64 bit), Java POS, OPOS and CUPS.

(CitizenCT-S651-USB-OB)

Printing Method Line thermal dot print method
Printing Width 80 mm / 640 dots, 72 mm / 576 dots, 64 mm / 512 dots, 54.5 mm / 436 dots, 54 mm / 432 dots, 52.5 mm / dots, 48 mm / 384 dots, 45 mm / 360 dots, 48.75 mm / 390 dots, 68.25 mm / 546 dots
Dot Pitch 8 x 8 dots / mm (203 dpi)
Printing Speed (Max.) Max. 200 mm/sec, 1600 dots lines / sec. (fastest, print density 100%)
Number of Columns 83 mm Paper: Font A - 53 columns, Font B - 71 columns, Font C - 80 columns
80 mm Paper: Font A - 48 columns, Font B - 64 columns, Font C - 72 columns
60 mm Paper: Font A - 36 columns, Font B - 48 columns, Font C - 54 columns
58 mm Paper: Font A - 35 columns, Font B - 46 columns, Font C - 52 columns
Character Size Font A:1.50 x 3.00 mm (12 x 24 Dots)
Font B:1.13 x 2.13 mm (9 x 17 Dots)
Font C: 1.00 x 2.00 mm (8 x 16 Dots)
Character Table/Code Pages Alphanumeric, International, PC437 PC850/852/857/858/860/863/864/865/866/
WPC1252/Katakana/Thai code 18
Bar-code Type UPC-A/E, JAN(EAN) 13/8 columns, ITF, CODE 39, CODE 128, CODABAR (NW-7), CODE 93, PDF417, QR Code
Line Spacing 4.23mm (1/6 inch) (changeable using commands)
Paper feed method Friction
Paper Type Thermal Paper Roll
Paper Width 83+0/-1 mm, 80+0/-1 mm, 60+0/-1 mm, 58 mm+0/-1
Paper Roll Diameter Max 80.0mm
Paper Thickness 0.065 - 0.075mm (core tube diameter: inner 12 mm/outer 18mm)
0.075 - 0.150mm (core tube diameter: inner 25.4 mm/outer 32 mm)
Paper Supply Method Easy Paper Loading, Drop in and Print
Auto Cutter Guillotine, Partial cut or Full cut
Indicators/Controls Power LED Green
Paper LED Orange
Error LED Red
Emulation ESC/POS
Optional:
iDP3540 Compatible
CBM710 Compatible
Star Emulation Compatible
Print Buffer 4K bytes / 45 bytes
NV Memory 384 Kb (capable of storing user-defined characters and logos)
Sensors Paper end Sensor
Printer Cover open Sensor
Drawer Port 1 port (opens 2 drawers, special cable is needed to open 2 drawers)
External Device Port RJ-45, 8-pin connector
Interfaces Standard without interface. Choice off:
Serial (RS-232C compliant), Parallel (IEEE1284 compliant), USB,
USB with hub, Ethernet, powered USB
Driver available WIN XP, WIN 7, OPOS, JAVAPOS, POS for .NET, CUPS
Software Utilities Utility software to customize print speed, darkness and to set up user font, logo, maintenance counter, etc.
Power Supply AC Adapter 36AD
Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA
Rated output: DC24 V, 2.1 A
ENERGY STAR qualified printer
Power Consumption Approx. 45 W (normal printing), 3W (standby)
External Dimensions (WxDxH) CT-S601 (Built-in power supply type): 145 x 192 x 148 mm
CT-S601N (No power Supply): 145 x 192 x 120 mm
Weight CT-S601 (Built-in power supply type): 2.0kg
CT-S601N (No Power Supply): 1.6kg
Operating Environment 5 to 45 °C, 10 to 90 % RH (no condensation)
Storage Environment -20 to 60 °C, 10 to 90 % RH (no condensation)
Reliability Print head life: 150 km, 200 million pulses (at normal temperature and humidity using recommended paper)
Auto cutter life: 2 million cuts (at normal temperature and humidity using recommended paper)
EMC/Safety Standards UL, C-UL, FCC class A, TUV-Bauart, CE marking, CCC, C-tick
SKU CitizenCT-S651-USB-OB
Barcode # 615678940437
Brand Citizen
Brand Citizen
Type Receipt Printer
Model CT-S651
Connectivity USB
Technology Thermal
Output Type Black & White
Input Type Monochrome
Shipping Cubic 0.017794000m3
