An enterprise-class, 2-socket, 2-Rack-Unit (2RU) server designed to deliver industry-leading performance, versatility, and expandability. It is purpose-built to handle a wide range of storage and I/O-intensive infrastructure workloads. The M5SX designation specifically refers to the expanded drive-bay model, supporting up to 26 Small Form Factor (SFF) 2.5-inch drives (24 front-accessible drives + 2 optional rear-accessible drives).  It is ideal for data-intensive applications such as virtualization, big data analytics, enterprise databases, and high-performance storage clusters.


Key Capabilities & Architecture

  • Processing: Powered by the Intel® Xeon® Scalable processors, delivering up to 20% more cores per socket compared to previous generations.

  • Massive Memory Footprint: Features 24 DDR4 DIMM slots (12 DIMMs per socket), supporting a total capacity of up to 3.0 TB of high-speed memory (or up to 6.0 TB when utilizing Intel® Optane™ Persistent Memory).

  • High-Density Storage: Supports up to 26 SFF drives (24 front + 2 rear), delivering massive local storage density in a 2U chassis and eliminating the need for external JBOD expansion in medium-scale deployments.

  • An enterprise-class, 2-socket, 2-Rack-Unit (2RU) server designed to deliver industry-leading performance, versatility, and expandability. It is purpose-built to handle a wide range of storage and I/O-intensive infrastructure workloads. The M5SX designation specifically refers to the expanded drive-bay model, supporting up to 26 Small Form Factor (SFF) 2.5-inch drives (24 front-accessible drives + 2 optional rear-accessible drives).  It is ideal for data-intensive applications such as virtualization, big data analytics, enterprise databases, and high-performance storage clusters.


    Key Capabilities & Architecture

  • Processing: Powered by the Intel® Xeon® Scalable processors, delivering up to 20% more cores per socket compared to previous generations.

  • Massive Memory Footprint: Features 24 DDR4 DIMM slots (12 DIMMs per socket), supporting a total capacity of up to 3.0 TB of high-speed memory (or up to 6.0 TB when utilizing Intel® Optane™ Persistent Memory).

  • High-Density Storage: Supports up to 26 SFF drives (24 front + 2 rear), delivering massive local storage density in a 2U chassis and eliminating the need for external JBOD expansion in medium-scale deployments.

  • Onboard I/O: Comes equipped with built-in dual 10GbBase-T Ethernet LAN ports on the motherboard alongside a dedicated 1GbE management port.

  • Advanced Remote Management: Includes integrated support for the Cisco Integrated Management Controller (CIMC). CIMC provides secure, web-based, out-of-band remote management, system monitoring, and diagnostics from anywhere, significantly reducing operational overhead.

  • Advanced Remote Management: Includes integrated support for the Cisco Integrated Management Controller (CIMC). CIMC provides secure, web-based, out-of-band remote management, system monitoring, and diagnostics from anywhere, significantly reducing operational overhead.



(CiscoC240M5Gold62421-r)

Product

Power Cable

Brand Cisco
Model C240 M5SX (HX Branded)
Form Factor 2RU Rackmount
Bays 24 Front 2.5", 2 Rear 2.5"
Processor 2x Xeon Gold 6242 2.8Ghz 16C (2nd Gen)
Memory 768GB (24x 32GB PC4 2666V)
Storage 1x 240GB M.2 SATA SSD
1x 240GB SATA SSD
1x 800GB SAS SSD
8x 1.2TB 10K SAS HDD
Raid Controller UCSC-SAS-M5HD (HBA)
Remote Acess CIMC
Networking Onboard RJ45, UCSC-MLOM-C40Q-03
PCIe Slots 6x High Profile
Adapter Cards None
Power Supply 2x 1050W
Rails Yes
Bezel Yes (No Key)
Operating System None
Dimensions 86.4x 740.3x 429.0 mm (3.4x 29.5x 16.9  inches, without bezel)
Weight 26 Kg
Other Features
Notes Bezel (HyperFlex Branded)
Drive caddy labels may vary or be missing
SKU CiscoC240M5Gold62421-r
Barcode # 615678951372
Brand Cisco
Brand Cisco
Form Factor 2RU Rackmount
Type Server
SSD Capacity 1x 240GB, 1x 240GB M.2
Series UCS
Storage Type M.2 SSD, SATA SSD, SAS SSD, SAS HDD
RAM Size 768 GB
Processor Speed 2.80 GHz
Model C240 M5SX (HX Branded)
DIMMs Installed 24x 32GB PC4 2666V
Drive Bays 24+2 Bay 2.5
Remote Access Management CIMC
RAID Controller UCSC-SAS-M5HD (HBA)
Power Supply 2x 1050W
Network Connectivity Wired-Ethernet (RJ-45, QSFP)
Processor Cores 16
UPC 615678951372
Processor Type 2x Intel Xeon Gold 6242
HDD Capacity 8x 1.2TB 10K
Memory Type DDR4 ECC-Registered
Shipping Cubic 0.105020000m3
