Appearance and specifications may differ from provided image, depending on AIB partner model/variation.

The GeForce GTX 680 was a high-end graphics card by NVIDIA, launched on March 22nd, 2012. Built on the 28 nm process, and based on the GK104 graphics processor, in its GK104-400-A2 variant, the card supports DirectX 12. Even though it supports DirectX 12, the feature level is only 11_0, which can be problematic with newer DirectX 12 titles. The GK104 graphics processor is an average sized chip with a die area of 294 mm² and 3,540 million transistors. It features 1536 shading units, 128 texture mapping units, and 32 ROPs. NVIDIA has paired 2,048 MB GDDR5 memory with the GeForce GTX 680, which are connected using a 256-bit memory interface. The GPU is operating at a frequency of 1006 MHz, which can be boosted up to 1058 MHz, memory is running at 1502 MHz (6 Gbps effective).
Being a dual-slot card, the NVIDIA GeForce GTX 680 draws power from 2x 6-pin power connectors, with power draw rated at 195 W maximum. Display outputs include: 2x DVI, 1x HDMI 1.4a, 1x DisplayPort 1.2. GeForce GTX 680 is connected to the rest of the system using a PCI-Express 3.0 x16 interface. The card's dimensions are 256 mm x 111 mm x 38 mm, and it features a dual-slot cooling solution.

(nvidiaGTX680-R)

GPU Memory 2 GB GDDR5
Memory Interface 256-bit
Memory Bandwidth 192.2 GB/s
NVIDIA CUDA® Cores 1536
System Interface PCI Express 3.0 x16
Max Power Consumption 195 W
Thermal Solution Active
Form Factor Dual Slot, Full Height
Display Connectors 2xDVI, HDMi, DP
Max Simultaneous Displays 4
Max Digital Resolution 4096 × 2160
Max VGA Resolution 2048 × 1536
Important Technologies GPU Boost, PhysX, TXAA, NVIDIA G-SYNC-ready
Other Supported Technologies 3D Vision, CUDA, Adaptive VSync, FXAA, 3D Vision Surround, SLI
OpenGL 4.2
Microsoft DirectX 12 API
SKU nvidiaGTX680-R
Barcode # 601527631342
Brand Nvidia
Type Graphics Card
Chipset Manufacturer NVIDIA
Memory Type GDDR5
Chipset/GPU Model NVIDIA GTX 680
Memory Size 2 GB
Shipping Cubic 0.017794000m3
