New, unused, Open Box item.

Cisco Webex™ Room 55 combines an unmatched video and audio experience with a sophisticated, Red Dot–awarded design to create a compelling team collaboration system.

The Room 55, which includes camera, codec, display, speaker system, and microphones integrated in a single device, is optimized for rooms that seat up to seven people. It is an all-in-one, integrated system that’s easy to install, use, deploy, and manage. It’s crafted with high-quality components: professional 4K display for longevity and minimal latency, powerful digital zoom camera for discreet tracking, sophisticated speaker system and amplifier to deliver rich sound, and a light industrial design that combines aluminum and fabric for a sustainable and humanizing effect.

The Cisco Webex Room 55 has the Cisco Webex Room Kit as its base technology, bringing new capabilities such as speaker tracking, best overview, automatic wake-up, and people count to enable even smarter meetings, smarter presentation capabilities, and smarter room and device integrations. These features and functionalities further remove the barriers to usage and deployment of video in small- to medium-sized meeting rooms. The Room 55 is rich in functionality and experience but is priced and designed to be easily scalable to all of your meeting rooms and spaces, whether registered on-premises or to Cisco Webex.

Feature

Benefit

Award-winning design

●  Light, sophisticated industrial design is recipient of 2017 Red Dot award for innovation in design

●  Camera innovation: Powerful 5K UltraHD camera and wide-angle lens cover everyone in the room

●  Sound innovation

◦    Stereo speakers with dedicated center speaker for optimal voice pick-up

◦    Built-in amplifier to deliver rich sound

◦    Speakers above screen for more equal room coverage

●  Screen innovation: 4K professional-grade screen

●  Design innovation

◦    Fabric front for natural and inviting feel

◦    Aluminium frame for lightness in design and sustainability

◦    Increased height over previous generation to accommodate taller tables (10 cm/4 inches taller than MX300)

●  Highly reliable as components and software are designed to work together

●  Designed to minimize latency and echo

Smart meetings

●  Brings intelligent views to smaller rooms with discreet, integrated camera

◦    Best overview: Automatically detects meeting participants and provides ideal framing

◦    Speaker tracking: Detects and switches between active speakers and provides ideal framing

●  Great audio experience with integrated microphones, speakers, and amplifier; supports room elegance with no wires or microphones on the table

●  Automatic noise suppression reduces disruptive sounds coming from the meeting room (e.g., typing, paper rustling)

●  Simplified meeting-join experience with One Button To Push (OBTP) for scheduled devices in a Cisco Webex meeting, whether registered on-prem or to Cisco Webex

●  Automatic wake-up: System “wakes up” when someone walks into the room and suggests activities for fast and easy meeting start

●  Easily controlled by the Cisco Webex Room Navigator control unit or with a Cisco Proximity or the Cisco Webex app

●  End-to-end security

Smart presentations

●  Supports dual screens for video and content

●  Supports dual content sources for local meetings

●  View white board content and annotations shared from Cisco Webex Board, Cisco Webex Desk Pro, or Cisco Webex app; participate in white boarding sessions through the Cisco Webex app *

●  4K content sharing (local 30 fps, remote 5 fps)

●  Wired or wireless content sharing (only two wires required: power and HDMI)

Smart rooms

●  Metrics: Counts people in the room, enabling analytics for better resource planning

●  Supports Wi-Fi

●  In-room control: Controls peripherals such as lights and blinds through the Webex Room Navigator

Built for cloud and premises

●  Flexibility to register on-premises or to the cloud through Cisco Webex

●  Hardware is optimized to run on a cloud platform for great experiences in shared rooms and spaces, with easy access to hosted conferences

(CiscoCSR55-K9-OB)

Specification

Description

Software compatibility

●  Cisco Collaboration Endpoint Software Version 9.14.5 or later, and Cisco Webex RoomOS

Optional hardware components

●  Microphone extension cable

●  HDMI presentation cable 8m/26.2 ft.

Bandwidth

●  Up to 6 Mbps point-to-point

Minimum bandwidth for resolution/frame rate

H.264:

●  720p30 from 768 kbps

●  720p60 from 1152 kbps

●  1080p30 from 1472 kbps

●  1080p60 from 2560 kbps

Firewall traversal

●  Cisco Expressway ™ technology

●  H.460.18, H.460.19 firewall traversal

Video standards

●  H.264

●  H.265

Video inputs

●  Two HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60; HDMI 2 supports HDCP content for local viewing

●  Consumer Electronics Control (CEC) 2.0

Video outputs

●  One HDMI output supports formats up to 3840 x 2160 at 60 fps (4Kp60)

●  Live video resolutions (encode and decode) up to 1920 x 1080 at 30, 60 fps (HD1080p)

●  Consumer Electronics Control (CEC) 2.0

Audio standards

●  G.711, G.722, G.722.1, G.729, AAC-LD, and Opus

Audio features

●  High-quality 20-kHz audio

●  Prepared for inductive loop (line out)

●  Automatic Gain Control (AGC)

●  Automatic noise reduction

●  Active lip synchronization

Audio inputs

●  Two microphones, 4-pin minijack

●  Two audio in from HDMI

●  Internal microphone

Audio outputs (external)

●  1 line out minijack (stereo)

Speakers (integrated)

●  High-quality speaker system with left, center, and right channels, plus woofer

●  Frequency response 70 Hz to 20 kHz

●  Amplifier power: 80W

●  Max output level SPL 98 dB

Speaker tracking

●  6-element microphone array for accurate speaker tracking

Display

●  55 in. (1.4m) LCD monitor, LED backlight

●  Resolution: 3840 x 2160 (16:9)

●  Contrast ratio: typical 1100

●  Viewing angle: +/- 178 degrees

●  Response time: typical 8 ms

●  Brightness: typical 500 cd/m2

Dual stream

●  H.239 (H.323) dual stream

●  Binary Floor Control Protocol (BFCP) (SIP) dual stream

●  Supports resolutions up to 3840 x 2160 at 5 fps

Wireless sharing

●  Cisco Webex app (up to 3840 x 2160 at 5 fps)

●  Cisco Intelligent Proximity client (up to 1920 x 1080 at 5 fps)

Multipoint support

●  4-way embedded SIP/H.323 conferencing capability with MultiSite option

MultiSite features (embedded multipoint) (optional upgrade)

●  Adaptive SIP/H.323 MultiSite:

◦    3-way resolution up to 1080p30 + content up to 4Kp5

◦    4-way resolution up to 720p30 + content up to 4Kp5

●  Full individual audio and video transcoding

●  H.323/SIP/VoIP in the same conference

●  Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5

●  Best impression (automatic continuous presence layouts)

●  Encryption and dual stream from any site

Protocols

●  H.323

●  SIP

●  Cisco Webex

Embedded encryption

●  H.323 and SIP point-to-point

●  Standards-based: H.235 v3 and Advanced Encryption Standard (AES)

●  Automatic key generation and exchange

IP network features

●  DNS lookup for service configuration

●  Differentiated services (Quality of Service [QoS])

●  IP-adaptive bandwidth management (including flow control)

●  Automatic gatekeeper discovery

●  Dynamic playout and lip-sync buffering

●  H.245 Dual-Tone Multifrequency (DTMF) tones in H.323

●  RFC 4733 DTMF tones in SIP

●  Date and time support using Network Time Protocol (NTP)

●  Packet loss-based downspeeding

●  Uniform Resource Identifier (URI) dialing

●  Dynamic Host Configuration Protocol (DHCP)

●  802.1X network authentication

●  802.1Q virtual LAN

●  802.1p (QoS and Class of Service [CoS])

●  ClearPath

Call control

●  Cisco Unified Communications Manager (CUCM)

◦    Native registration with CUCM

◦    Requires CUCM Version 10.5.2 or later with device pack for Room 55

●  Cisco Expressway

◦    Native registration with Expressway

●  Cisco Webex

●  Third-party H.323 Gatekeepers and standards-based SIP proxies

IPv6 network support

●  Single call stack support for both H.323 and SIP

●  Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ

●  Support for both static and automatic IP configuration (stateless address auto-configuration)

Security features

●  Management using HTTPS and SSH

●  IP administration password

●  Menu administration password

●  Disable IP services

●  Network settings protection

Certificate management

●  Certificate Authority Proxy Function (CAPF) support for additional security

●  Manufacturer-Installed Certificates (MIC)

●  Locally Significant Certificates (LSC)

●  X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported

Other interfaces

●  USB 2.0 port type A, USB 2.0 port type B, mUSB, factory reset pinhole

Power

●  Autosensing power supply

●  100-240 VAC, 1.8-0.8A, 50/60 Hz

●  Rated: 142W maximum

●  Power consumption: 142W at maximum standardized configuration

●  Standby power consumption: 40W

Operating temperature and humidity

●  0°C to 40°C (32°F to 104°F) ambient temperature

●  10% to 90% Relative Humidity (RH)

Storage and transport temperature

●  -20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (noncondensing)

Physical dimensions (H x W x D)

Cisco Webex Room 55 with:

●  Floor stand: 62.7 x 49 x 30.5 in (1593 x 1245 x 774mm)

●  Wall mount: 32.8 x 49.0 x 5.1 in (832 x 1245 x 130mm)

●  Wheel base: 62.7 x 49.0 x 30.5 in (1651 x 1245 x 774mm)

Weight

Cisco Webex Room 55 with (all weight without packaging):

●  Floor stand: 83.8 lb (38kg)

●  Wall mount: 68.3 lb (31kg)

●  Wheel base: 85.1 lb (38.6kg)

●  Main unit only: 66.1 lb (30kg)

Physical dimensions and weight of packaging (H x W x D)

Cisco Webex Room 55 package size with:

●  Floor stand: 42.5 x 54.3 x 17.3 in (1080 x 1380 x 440mm)

●  Wall mount: 46.9 x 53.9 x 17.3 in (1190 x 1370 x 440mm)

●  Wheel base: 42.5 x 54.3 x 17.3 in (1080 x 1380 x 440mm)

Cisco Webex Room 55 shipping weight with:

●  Floor stand: 110 lb (50kg)

●  Wall mount: 88 lb (40kg)

●  Wheel base: 110 lb (50kg)

Camera overview

●  5K UltraHD camera

●  Supports up to 60 fps (max 30 fps with speaker tracking and best overview enabled)

●  15.1 MP image sensor (5184 x 2916 pixels)

●  1/1.7 CMOS

●  3x zoom

●  f/2.0 aperture

●  83° horizontal field of view/51.5° vertical field of view

●  Auto-framing (audio + face detect)

●  Autofocus, brightness, and white balance

●  Focus distance 1m to infinity
SKU CiscoCSR55-K9-OB
Barcode # 889728044202
Brand Cisco
Brand Cisco
Type Video Conferencing
Model CS Room 55 NR-K9
Shipping Cubic 0.017794000m3
