Utilizing an innovative display connection technology and a set of passive cables, the Belkin Universal 2nd Gen Secure KVM (SKVM) Switch can simultaneously accommodate legacy DVI-D input/output as well as modern, high-resolution HDMI and DisplayPort™ input/outputs on the same SKVM. The pioneering connector design and internal video conversion allows the same SKVM to be used for legacy systems and accommodates anticipated technology changes over time, ensuring today’s investment is not rendered obsolete as underlying systems get upgraded.

The Belkin Universal 2nd Gen SKVM is the ideal solution for systems using high-performance DisplayPort graphics outputs as well as monitor inputs. The platform is fully compatible with Display Port and HDMI® connections supporting resolutions of UHD 4K @60Hz. The platform’s flexibility also allows support for standard definition and HD resolutions supported by DVI-D without the need for unreliable and costly external converters. The platform is truly plug and play now and into the future.

(F1DN104KVM-UNN4-R)

# of Systems Supported

4

Console I/O

2x USB-A (Keyboard/Mouse) Female
1x RJ14 (Remote) Female
1x 1/8" / 3.5 mm Female
1x HDMI/DisplayPort Female

KVM I/O

4x USB-B (Keyboard/Mouse) Female
4x HDMI/DisplayPort Female
4x 1/8" / 3.5 mm Female

OS Compatibility

Windows / Linux / macOS 10.3 or Later

Supported Resolutions

3840 x 2160 @ 60 Hz

USB Keyboard/Mouse Emulation

No

Power Source

AC Adapter

Input Power

100 to 240 VAC, 50 / 60 Hz

Operating Conditions

32 to 104°F / 0 to 40°C up to80% Humidity

Storage Conditions

-4 to 140°F / -20 to 60°C

Certifications

CE, FCC Class A, ICES, RCM, RoHS, TAA, UL

Rack Mountable

No

Material of Construction

Aluminum, Metal

Dimensions

12.5 x 6.2 x 1.9" / 317.5 x 157.5 x 48.3 mm

Weight

3.9 lb / 1.8 kg

SKU F1DN104KVM-UNN4-R
Barcode # 601527895430
Brand Belkin
Brand Belkin
Type KVM Switch
model F1DN104KVM-UNN4
Shipping Cubic 0.017794000m3
