Not all printers are created equally, especially basic models. To reduce costs, value printers are often constructed using less expensive components. Many fail to perform under more demanding duty cycles, create delays and downtime for repairs, and require replacement after only a few years of use. Instead of conserving budget, customers are left with greater expense and hassle. Zebra does it differently. The ZD220 desktop printer gives you reliable operation and basic features at an affordable price—both at the point of purchase and across the entire lifecycle. Engineered with Zebra quality, it boasts a dual-wall construction for added durability. And, it is ENERGY STAR™ qualified to reduce your operational expenses. Built to last for years, the ZD220 provides an outstanding return on your investment.

Basic Features for Simple Operation

This 4-inch printer produces labels quickly, at 4 in. per second, to keep your workflows moving. Increased memory allows you to store more fonts and graphics. A single LED indicator and single button for feed/pause make it easy to operate and identify printer status. Choose from direct thermal or thermal transfer models, and add an optional factory-installed peeler. The ZD220 features Print DNA™ Basic, a core set of software applications and capabilities to deliver a cost-effective and dependable print experience.

Get Printing Quickly

The ZD220 is simple to install and begin printing—right out of the box. USB connectivity allows for universal interoperability. Easily replace legacy printers using ZPL, EPL or non-Zebra command languages. And, media changes are expedited with Zebra’s OpenACCESS™ clamshell design. It is ideal for use in transportation and logistics, light manufacturing, retail and healthcare applications to print a variety of tickets, tags, passes, labels and receipts.

(ZD220-R)

Physical Characteristics

Dimension Direct Thermal:
8.6 in. L x 6.9 in. W x 5.9 in. H
220 mm L x 176 mm W x 151 mm H
Weight Direct Thermal:
2.5 lbs./1.1 kg

Printer Specifications

Resolution 203 dpi/8 dots per mm
Memory 128 MB Flash; 128 MB SDRAM
Maximum Print Width 4.09 in./104 mm
Print Speed 4 in./102 mm per second
Media Sensors Movable black mark sensor, limited range from center to left side
Fixed off-center gap sensor
Firmware ZPL II; EPL 2; XML

Media and Ribbon Characteristics

Maximum Label Length 39.0 in./991 mm
Media Width 1.00 in./25.4 mm to 4.4 in./112 mm
Media Roll Size 5.00 in./127 mm outer diameter
Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1 mm) using optional adapters
Thickness 0.003 in. (0.08 mm) min.; 0.0075 in. (.1905 mm) max. (tear-off mode only)
Media Types Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
Ribbon Outside Diameter 1.34 in./34 mm (74 m)
Maximum Ribbon Length 244 ft. (74 m)
Ribbon Ratio 1:1 ribbon to media (74 m)
Ribbon Width 1.33 in./33.8 mm-4.3 in./109.2 mm
Ribbon Core I.D. 74 meter ribbon 0.5 in./12.7 mm

Operating Characteristics

Operating Temp. 40° to 105° F/4.4° to 41° C
Storage Temp.

-40° to 140° F/-40° to 60° C

Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Electrical Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR qualified

Fonts/Graphics/Symbologies

Bar Code Ratios 2:1 and 3:1
1D Bar Codes Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Bar Codes Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Fonts and Graphics 16 resident expandable ZPL II bitmap fonts
Two resident scalable ZPL fonts
Five resident expandable EPL2 fonts
Native open-type font support
Unicode compliant for multi-language, on demand thermal printing
50 MB user available non-volatile memory,  8 MB user available SDRAM
SKU ZD220-R
Barcode # 615678936744
Brand Zebra
Brand Zebra
Type Label Printer
Model ZD220
Maximum Resolution 203 dpi
Connectivity USB
Technology Thermal
Shipping Cubic 0.017794000m3
