Bring Your Walls to Life

For the most engaging and creative visual experiences, the MultiSync® UN552S video wall display offers better image quality, easier installation and a reliable longer-lasting performance.

Installation and operation becomes so simple as powerful calibration capabilities provide compelling picture performance throughout the display’s entire lifetime. Tune picture attributes according to your specific application needs and create a single image across multiple displays. With a combined adjoining bezel of just 0.88mm, the holistic video wall experience offers an expansive digital canvas with barely noticeable interruption. The 700cd/m² display brightness and an anti-glare surface delivers the best readability with no annoying reflections even in bright ambient light conditions.

Attracting shoppers in retail malls, entertaining museum-goers or presenting menu choices, these large modular displays, in different shapes and formations, get your content noticed.

Benefits

  • Easy installation – effortlessly set up you wall display with Auto TileMatrix and out-of-the-box calibrations. Save time by plugging in ready-to-use image presets for predefined application scenarios.
  • Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
  • Secure Reliability and Longevity of Video Walls – unique NEC heat management system enables the user to monitor and control the heat inside the display.
  • Smart media integration – seamlessly integrate the media source of your choice into the video wall display. Use the wide range of NEC’s OPS Slot-in PCs, and Raspberry Pi compute modules, for content feed and computing.
  • Lifelike and consistent colour – expect colour reproduction that feels true to life with IPS panel technology, the top choice when it comes to colour consistency. The S-IPS panel ensures that perfect visibility is maintained in landscape and portrait mode and at extreme viewing angles as viewers pass by.

(NEC-UN552S-OB)

Product Specifications

DISPLAY UN552S
Panel Technology S-IPS with Direct LED backlights
Active Screen Area (W x H) [mm] 1,209.6 x 680.4
Screen Size [inch/cm] 55 / 138.8
Aspect Ratio 16:9
Pixel Pitch [mm] 0.630
Brightness [cd/m²] 700
Contrast Ratio (typ.) 1700:1
Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time [ms] 8
Panel Refresh Rate [Hz] 60
Haze Level [%] Pro (28)
Supported Orientation Landscape; Portrait
SYNCHRONISATION RATE
Horizontal Frequency [kHz] 26 - 134
Vertical Frequency [Hz] 23 - 86
RESOLUTION
Native Resolution 1920 x 1080 at 60 Hz
Supported on DisplayPort and HDMI 3840 x 2160;
  1920 x 1080;
  1600 x 1200;
  1360 x 768;
  1280 x 1024;
  1280 x 768;
  1080i;
  1080p;
  1024 x 768;
  800 x 600;
  720p (50/60 Hz);
  640 x 400
Supported on HDMI only 1080i (50/60 Hz)
CONNECTIVITY
Input Video Analogue 1 x VGA; Composite (RCA)
Input Video Digital 1 x DVI-D (with HDCP); 1 x OPS Slot; 2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
Input Audio Analogue 2 x 3.5 mm jack
Input Audio Digital 2 x DisplayPort; 2 x HDMI
Input Control 1 x Remote Control (3.5 mm jack); 1 x RS232; 2 x LAN 100Mbit
Input Data 1 x microSD (MediaPlayer); 1 x USB 1.0 (Downstream); 1 x USB 1.0 (MediaPlayer); 1 x USB 2.0 (Upstream); 2 x USB 1.0 (Compute Module, 1 x 5V/2A powered)
Output Video Digital 1 x DisplayPort (loop through: DisplayPort, OPS slot-in PC); 1 x HDMI (loop through: HDMI, OPS slot-in PC, Mediaplayer)
Output Audio Analogue 1 x 3.5 mm jack
Output Control LAN 100Mbit
CALIBRATION
Factory Calibration Gamma; Intensity; RGB; Uniformity; White Point
Sensor Calibration (through USB) PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration)
Calibration with Software Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; Update Uniformity Correction; White Point
Calibration Software NEC Display Wall Calibrator
OPEN MODULAR INTELLIGENCE
OPS Slot Slot Technology: Open pluggable specification (NEC / Intel OPS standard)
OPS Max. Current / Power
Consumption [A / W]		 3.6 / 58
Compute Module Slot Slot Technology: Compute Module Slot (NEC proprietary standard)
SENSORS
Human Sensor Optional, external, 4-5m range, triggered actions programmable
Temperature Sensor Integrated, 3 sensors, triggered actions programmable
NFC Sensor Integrated, 2cm range, free NEC Android App required
ELECTRICAL
Power Consumption Eco/max. [W] 165 shipping; 420 (max.)
Power Savings Mode [W] < 0.5; < 2 (Networked Standby)
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] +0 to +40
Operating Humidity [%] 20 to 80
Storage Humidity [%] 10 to 90
Storage Temperature [°C] -20 to 60
MECHANICAL
Dimensions (W x H x D) [mm] Without stand: 1,210.5 x 681.2 x 98.6
Weight [kg] Without stand: 25.8
Bezel Width [mm] 0.44 bottom/right; 0.44 top/left; 0.88
VESA Mounting [mm] 4 holes; 400 x 400 (FDMI); M6
MEDIA PLAYER
Supported Image Formats JPG (baseline, progressive, RGB, CMYK); max. resolution 5000 x 5000; PNG (interlace, alpha channel); max. resolution 4000 x 4000
Supported Video Formats MP4 / MOV / FLV (video H.264, audio MP3, AAC); max. resolution 1080p at 30 Hz, 1080i at 60Hz; MPG (video mpeg1/2, audio mpeg audio layer2/3, AAC-LC); MP @ ML, MP @ HL; WMV (video H.264, wmv advanced L3, wmv simple / main, audio mp3 wmv std); max. resolution 1080p at 30 Hz, 1080i at 60 Hz
Supported Audio Formats MP3 (MP3); max. bit-rate 320 kBit/s; WAV (LPCM); max. 48 kHz sampling
AVAILABLE OPTIONS
Accessories Calibration kit (KT-LFD-CC2); Feet (ST-5220); Remote control kit (KT-RC3); Speaker (SP-TF1)
Compute Module Slot Raspberry Pi Compute Module 1 and 3
OPS Slot Intel® Atom, Celeron and Core i3, i5, i7 Slot-in PCs
GREEN FEATURES
Energy Efficiency Annual energy consumption: 291 kWh (based on 4 operating hours per day); Carbon savings
meter; Energy efficiency class: C; Human Sensor; LED backlight
Ecological Standards EnergyStar 8.0
Additional Features
Special Characteristics Auto ID assignment; Auto tiling function; Automatic Alarm E-Mails; DICOM Simulation; Frame Comp; HTTP Server; Image flip; Intelligent Wireless Data (based on NFC); NaViSet Administrator 2; PJLink Support; TileMatrix; USB Media Player; User input priority definition; User readable log function
Colour Versions Black Front Bezel, Black Back Cabinet
Safety and Ergonomics BSMI; CE; EAC; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
Pixel Failure Class ISO 9241-307, Class 2
Audio Optional Speakers (15 W + 15 W)
Plug and Play VESA DDC/CI
Shipping Content Display; DisplayPort Cable; HDMI Cable; LAN cable (RJ45); Power Cable
Operating Hours 24/7
SKU NEC-UN552S-OB
Barcode # 5028695115514
Brand NEC
Brand NEC
Type Commercial Display
Screen Size 55"
Model UN552S
Shipping Cubic 0.017794000m3
