Includes Rally Bar Mini, USB-A to USB-C Cable, power adapter. Does NOT include remote, USB Type-C to Type-C cable, HDMI cables.

PREMIER VIDEO BAR FOR SMALL TO MEDIUM MEETING ROOMS

Logitech Rally Bar Mini raises the bar for video meetings in small and medium rooms. Rally Bar Mini is remarkably simple to deploy, use, and manage remotely.

Plug and play Rally Bar Mini with any PC or laptop, or leverage its built-in compute and use it in appliance mode. Rally Bar Mini works with most platforms you use to connect hybrid teams, ensuring an effortless experience from the home to the office, and everywhere in between.

Plus, Rally Bar Mini easily integrates with meeting controllers like Tap IP and other accessories like Rally Mic Pods, making it easy to build a video conferencing experience ideal for both in-office and virtual meeting attendees.

(LogiRallyBarMini-PSU-R)

Dimensions

  • Height: 91.4 mm
  • Width: 719 mm
  • Depth: 101 mm
  • Lens Depth: 18.5 mm
  • Weight: 4.03 kgs

Technical Specifications

Certifications & Compatibility

  • For the latest information on certifications and compatibility, visit www.logitech.com/support/vc-certifications
  • Microsoft Teams Rooms on Android
  • Microsoft Teams Rooms on Windows

General Specifications

  • Built-in Components: 6 beamforming microphones, PTZ camera, 3 speakers, AI Viewfinder, cable management and retention system, table stand, Logitech CollabOS platform
  • Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference
  • Device Management: Logitech Sync
  • Displays Supported: 2
  • Display Resolution: Up to 1080p
  • Network Protocol Support: IPv4, IPv6
  • Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file

Camera

  • Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
  • Pan: Motorized ±25°
  • Tilt: Motorized ±15°
  • Zoom: 4X HD digital zoom
  • Diagonal Field of View: 120°
  • Horizontal Field of View: 113°
  • Vertical Field of View: 80.7°
  • Total Room Coverage (field of view + pan and tilt): 163° horizontal x 110° vertical

Woofer Speaker

  • Driver: 70 mm
  • Sensitivity: 92dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter
  • Rated Power: 8W
  • THD: 1kHz < 2% at 1W
  • Speaker Sampling Rate: 48KHz
  • Impedance: 4 Ohms

Midrange Speakers

  • Drivers: 2 x 43mm
  • Sensitivity: 84 dB SPL @ 1W/1M
  • Rated Power: 4W
  • THD: 1kHz < 2% at 1W
  • Speaker Sampling Rate: 48KHz
  • Impedance: 4 Ohms

Microphones

  • Frequency Response: 90Hz – 16kHz
  • Sensitivity: >-36dBFS +/-1 dB @ 1Pa
  • Microphone data rate output: 48 kHz
  • Pickup Range: Up to 7 m
  • Beamforming Elements: 6 omnidirectional digital MEMS microphones forming 5 adaptive acoustic broadside beams
  • Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
  • Noise suppression: AI based de-noising algorithm
  • Add-on Mics: Supports up to 3 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms

RightSense™ Technologies

  • RightLight: Renders natural skin tones for each participant
  • RightSight: Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room
  • RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo
  • Grid View: Detects and frames all meeting participants in order to create equitable hybrid meeting experiences. To learn more, visit logitech.com/prosupport/gridview

Interfaces

  • HDMI Out: 2 (up to 1080p)
  • HDMI In: 1
  • USB: 3x Type A, 1x Type C
  • Network: 10/100/1G Ethernet
  • WiFi: 802.11a/b/g/n/ac
  • External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
  • Remote Control: Bluetooth® Low Energy

Power & Cables

  • Power supply: Auto-sensing
  • Operating Voltage/Power: 100-240V, 19V, 4.74A
  • Power Supply Dimensions: 127 mm x 51 mm x 30 mm
  • DC Cable: 1.5 m
  • AC Cable: 1 m
  • HDMI 1.4 Cable: 2 m
  • USB A to USB C 3.0 Cable: 2.2 m

Environmental

  • Operating Temperature: 0 to 40°C
  • Storage Temperature: -40 to 70°C
  • Humidity: 10 to 95%
  • BTU/hr: 57 idle, 64 in meeting

Security

  • Full Disk Encryption: AES-128
  • Data Encryption: Symmetric Keys, PKI
  • Device Identity: Protected by device attestation
  • Device Access: Authenticated using API
  • Key Protection: Arm TrustZone, RPMP

Accessories

  • Mounts: Wall Mount for Video Bars, TV Mount for Video Bars
  • Audio: Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable
  • Connectivity: Logitech Strong USB (10m, 25m, 45m)
  • Touch Controller: Logitech Tap and Tap IP
SKU LogiRallyBarMini-PSU-R
Barcode # 634855386240
Brand Logitech
Brand Logitech
Model Logitech Rally Bar Mini
Connectivity USB
Shipping Cubic 0.017794000m3
